Emerson Ovation 5X00226G02 Input Output Interface Module

PK Controller: Now Supporting Native PROFINET

PROFINET is an open industrial Ethernet solution and is based on international standards.

It is a communication protocol designed to exchange data between controllers and devices in an industrial automation network.

And now, both the innovative PK Controller and new PK Flex Controller support native PROFINET,

helping customers enhance their performance and meet the requirements of most of their time-critical applications.

You do not need special hardware or configuration to use PROFINET;

the PK Flex Controller and PK Controller are equipped with PROFINET capability.

„ PK Flex Controller is a PROFINET controller and will connect with up to 250 devices such as PLCs, Drives,Remote I/O, transmitters and valves.

„ PROFINET in the PK Flex Controller is compliant with version 2.3 and CC-A functionality.

The Ovation I/O modules are locked into base units. These base units are housed in

the Controller cabinets where they are mounted on DIN rails and wired to the appropriate field devices.

Tighter, More ReliableControl

The Ovation system is renowned for delivering precision control with outstanding performance.

That precision begins with the Ovation Controller. With an Intel-based

processor at its heart, the Ovation Controller provides full-redundancy to assure the reliability

and security necessary for even the most demanding application.

In addition to a comprehensive set of over 100 standard algorithms,

Ovation also provides the ability to embed advanced control algorithms that leverage the ever expanding

computing power of the Ovation Controller.

This capability allows you to take control to a higher level by incorporating model predictive control and

industry specific advanced applications to reduce process variability and optimize performance over the full range of plant operating conditions.

Overview

Ovation is a modular system. It permits the configuration of the process

management system exactly as it is needed. A small installation can be expanded to

include as many as 254 intelligent modules (referred to as drops). Each drop is a

separate module that can perform various functions. The Controller is the drop

containing the printed circuit cards (I/O) that are attached to sensors on the actual

plant equipment. The point values measured by these sensors are broadcast onto the

Highway via the drop.

The Operator Station is a drop in the Ovation System that enables the user to view

and control the current status of the plant process control system. The Operator

Station can display many diagrams that allow the user to communicate with plant

processes using other drops. Also, the user can monitor and control alarm

conditions, enter point information, and create trends.

This document describes the functions of the Operator Station and how to use them.

DeltaV™ Version 15 continues to set the pace in shaping the future of automation with Feature Pack 1 updates.

When it comes to preparing operations with future-proof automation technologies that not only propel performance

and production but help to accelerate digital transformation, DeltaV Version 15 Feature Pack 1 provides a collection of

updates and new functionality that deliver.

The standard modular components typically consist of the following:

• Electronics module

• Personality module

• Base Unit (containing the field terminations)

The relay output modular components consist of the following:

• Electronics module

• Base Unit (containing the field terminations)
