Product Description P/N: QPI-3D200-E2P DESCRIPTION / SPECIFICATIONS Description The QPI-3D200-E2P model of human/machine interface touch screen is built with an amber electroluminescent visual display. Technical Specifications Brand General Electric Category HMI / MMI / OIT Part Number QPI-3D200-E2P Subcategory Operator Interface Series QuickPanel Screen Size 8.9" LCD Type High Intensity EL Input Voltage 24 VDC NEMA Rating Type 4X/12 IP65 Software Version QuickDesigner Version 3.7 Information About QPI-3D200-E2P The QPI-3D200-E2P is an advanced Operator Interface device manufactured by General Electric, specifically designed for use in industrial environments where reliable human-machine interaction is essential. As part of the QuickPanel series, this operator interface unit provides a user-friendly platform for monitoring and controlling complex industrial processes, making it an indispensable tool for operators who need to ensure the smooth operation of machinery and systems. With a screen size of 8.9 inches, the QPI-3D200-E2P offers ample display area for viewing critical information and interacting with the system. The device is equipped with a high-intensity EL (Electroluminescent) LCD, which provides clear and bright visuals, even in challenging lighting conditions. This high-quality display ensures that operators can easily read data and navigate the interface, reducing the likelihood of errors and enhancing overall efficiency.

The QPI-3D200-E2P operates on a 24 VDC input voltage, making it compatible with a wide range of industrial power supplies. This voltage rating ensures that the device can be easily integrated into existing systems without the need for extensive modifications, simplifying the installation process and minimizing downtime. The use of a standard DC input also contributes to the device's reliability, as it can operate consistently across various industrial environments. One of the key features of the QPI-3D200-E2P is its robust construction, which includes a NEMA Type 4X/12 IP65 rating. This rating indicates that the device is protected against water, dust, and other environmental hazards commonly encountered in industrial settings. The Type 4X rating specifically highlights the unit's resistance to corrosion, making it suitable for use in harsh environments such as those involving exposure to chemicals or saltwater. The IP65 rating further ensures that the device is dust-tight and protected against low-pressure water jets, providing additional assurance of its durability and longevity. The QPI-3D200-E2P is designed to be used with QuickDesigner Version 3.7 software, which allows operators to create and customize their interface screens. This software provides a flexible and intuitive platform for developing HMI (Human-Machine Interface) applications tailored to specific industrial processes. The ability to customize the interface ensures that operators can access the information and controls they need most, enhancing their ability to manage complex systems efficiently. In addition to its advanced features, the QPI-3D200-E2P is part of the well-regarded QuickPanel series, known for its reliability and ease of use. The series is designed to meet the needs of industrial operators who require a dependable interface for interacting with machinery and systems. The QPI-3D200-E2P upholds this reputation by offering a combination of robust construction, clear display, and user-friendly software, making it an excellent choice for a wide range of industrial applications. The design of the QPI-3D200-E2P also emphasizes ease of integration and operation. Its compact size and standardized mounting options allow it to be easily installed in control panels or other operator stations. Once installed, the device's intuitive interface and responsive touch controls enable operators to quickly access critical system information and make adjustments as needed. This ease of use is particularly valuable in fast-paced industrial environments where quick decision-making is essential. In summary, the QPI-3D200-E2P from General Electric is a highly reliable and versatile Operator Interface device designed for demanding industrial applications. With its 8.9-inch high-intensity EL LCD, 24 VDC input, and robust NEMA Type 4X/12 IP65 rating, the device is built to withstand the challenges of industrial environments while providing clear and accessible control interfaces. Manufacturer information General Electric (GE) is a multinational conglomerate founded in 1892, based in the United States. It operates in various industries, including aviation, healthcare, renewable energy, and power. GE is known for its innovations in technology, manufacturing, and infrastructure solutions. IQElectro is not an authorized distributor. QElectro LLC (IQElectro) is NOT an Authorized Distributor or in any way affiliated with Rockwell Automation, Siemens, or any other Manufacturers. IQElectro is NOT an Authorized Dealer of this product. The product may be of older version, date codes, or design than that available from authorized dealers. As IQElectro is not an authorized dealer of this product, the Original Manufacturer's Warranty and Support DO NOT apply.IQElectro sells SURPLUS onlyand DOES NOT SELL SOFTWARE or FIRMWARE licenses For more detailed information, please refer to the full version of our disclaimer policy Disclaimer Policy.
