531X210DMCAMM1 | General Electric Interface Processor Board

Product Description P/N: 531X210DMCAMM1 DESCRIPTION / SPECIFICATIONS Description The 531X210DMCAMM1 is an interface processor board designed for integration into control systems. It features a range of connectors and components that facilitate communication between various system modules. The board is used to manage data processing and interface tasks within the system, ensuring effective signal handling and processing. Technical Specifications Condition New / Never Used Surplus Part Number 531X210DMCAMM1 Type PC Board Assembly Ports 1 female port, 3 black male ports, 1 small white male port Oscillators 2 crystal oscillators for precise frequency generation LEDs 2 raised red LEDs Jumpers Over 20 jumpers with multiple positions for circuit control Capacitors Various types including tiny beads, large cylindrical, thin bar, and tall cylinders Fuses 3 fuses placed around large cylindrical capacitors Button 1 small button on the circuit board Diodes Multiple diodes for controlling energy flow Resistors Multiple resistors for energy dissipation Integrated Circuits 47 integrated circuits with space for 2 additional Information About 531X210DMCAMM1 The 531X210DMCAMM1 is a printed circuit board (PCB) assembly designed for use in industrial applications. The board features one female port, three black male ports, and one small white male port for connectivity. It incorporates two crystal oscillators that generate precise frequencies necessary for the board's operation. Additionally, the board is equipped with two raised red light-emitting diodes (LEDs) which serve as indicators for operational status.

The 531X210DMCAMM1 includes over twenty jumpers. Each jumper has at least two positions, enabling it to function as a switch that controls circuit connections and directs the flow of electrical energy. The board utilizes various types and styles of capacitors, including tiny bead capacitors, large cylindrical capacitors, thin bar capacitors, and tall cylindrical capacitors. These capacitors create individual electrical fields used to store and manage electrical current for the board's operation. To ensure protection and reliability, the 531X210DMCAMM1 is equipped with three fuses, which are strategically placed around the larger cylindrical capacitors. The board also features one small button intended for user interaction or system reset functions. Manufacturer information General Electric (GE) is a multinational conglomerate founded in 1892, based in the United States. It operates in various industries, including aviation, healthcare, renewable energy, and power. GE is known for its innovations in technology, manufacturing, and infrastructure solutions. IQElectro is not an authorized distributor. QElectro LLC (IQElectro) is NOT an Authorized Distributor or in any way affiliated with Rockwell Automation, Siemens, or any other Manufacturers. IQElectro is NOT an Authorized Dealer of this product. The product may be of older version, date codes, or design than that available from authorized dealers. As IQElectro is not an authorized dealer of this product, the Original Manufacturer's Warranty and Support DO NOT apply.IQElectro sells SURPLUS onlyand DOES NOT SELL SOFTWARE or FIRMWARE licenses For more detailed information, please refer to the full version of our disclaimer policy Disclaimer Policy.
