Emerson Rosemount 3051L Level Transmitter

The Rosemount 114C Thermowell is made from solid barstock to ensure strength and integrity.

The Rosemount 114C was designed to accommodate a host of industry standard configurations,

but has the flexibility to adapt to special configurations for different types of applications.

Flexible design modifiers accommodate many process requirements

■ Different sizes of root (A), tip (B), and bore (d) diameters

■ Different tip (t) thickness as required

■ Numerous combinations for various industrial applications

■ Meet ASME PTC 19.3 TW standard with flexible design

Physical specifications

Material selection

Emerson provides a variety of Rosemount products with various product options

and configurations including materials of construction that can be expected to perform

well in a wide range of applications. The Rosemount product information presented is

intended as a guide for the purchaser to make an appropriate selection for the application.

It is the purchaser’s sole responsibility to make a careful analysis of all process parameters

(such as all chemical components, temperature, pressure, flow rate, abrasives,

contaminants, etc.), when specifying product materials, options, and components for

the particular application. Emerson is not in a position to evaluate or guarantee the

compatibility of the process fluid or other process parameters with the product options,

configuration, or materials of construction selected.

Temperature sensors are rarely inserted directly into an industrial process.

They are installed into a thermowell toisolate them from the potentially damaging

process conditions of flow-induced stresses, high pressure, and corrosivechemical effects.

Thermowells are closed-end metal tubes or barstock installed into the process vessel

or piping and become an integral pressure-tight part of the process vessel or pipe.

They permit the sensor to be quickly and easily removed from the process for calibration

or replacement without requiring a process shutdown and possible drainage

of the pipe or vessel.
