Honeywell PRO22ENC3 Professional Series Access Enclosure

The PRO3200 professional series family of access control

modules is designed for high density installations.

Supporting up to 16 readers per enclosure and 32 readers

per intelligent controller along with up to 100.000 card

capacity provides a combination of small installation

footprint and superior cost per door ratio.

The PRO22R1 provides I/O support for one card access

reader, while the PRO32R2 supports two card access

readers. Both interface with the intelligent control module

(PRO32IC). In the event that communication to the

intelligent control module is lost, the card access readers

can be individually configured to allow entrance based on

security needs. This customization allows for a door to be

configured as locked, unlocked, or access only via valid

facility code.

The PRO32OUT interfaces with the intelligent control

module

(PRO32IC) providing up to 12 or 16. Form C, 12 VDC, 2A

relay output controls depending if the board is rack or tile

mounted and power fail and panel tamper when tile

mounted. Relays may be used for elevator control, status

annunciation and for general facility control, such as door

monitoring.

The PRO32IN interfaces with the intelligent control module

(PRO32IC) providing 16 supervised alarm inputs and a

dedicated power fail and panel tamper when tile mounted.

An analog to digital converter samples the input values and

the digitized result is filtered and processed. Filter

parameters are configurable for each input point, resulting

in the ability to specify a custom End-Of-Line (EOL)

resistance value, sensitivity range and timing parameter.

The PRO3200 Series of access modules are designed to

accommodate various mounting options. Units can be

mounted in a rack configuration (PRO22ENC1.

PRO22ENC2 and PRO22ENC5) when space is limited, or in

a tile-mount configuration (PRO22ENC3).

• The PRO22ENC1 is a wall-mounted enclosuree rack uni

• The PRO22ENC2 is a 19" rack-mounted enclosuree rack uni

• The PRO22ENC5 is a rack unit which fits inside a

customer’s enclosure

BENEFITS

•Anti-passback support - free pass and exempt flags, last area

accessed, last reader accessed and time/date of last access

•Modular hardware architecture provides flexibility and expansion

capabilities

•Large, local controller database allows access control decisions to

be made by controller in real time without the need to communicate

to the server

•ADA compliant allowing expanded door times selectable per reader

•Scalable architecture ensures optimal performance with a seamless

upgrade path to accommodate future growth beyond its initial installation

•Four-state alarm input circuits normally opened, normally closed,

non-supervised, supervised (w/EOL)

•Rack or tile mounting options available

•Alarm conditioning with programmable sensitivity and hold time

•Selectable reader states include card and PIN, card or PIN, card only,

or PIN only

•Auto switching power supply allows 110 / 220 operation

•System off-line modes customizable per reader include facility code

access, locked (no access), and unlocked (full access)

•Supports multiple reader and card formats for maximum flexibility

and security options
