Foxboro P0970BP RS-423 (Internal) Cable Assembly

The FCP280 performs regulation, logic, timing and sequence control,

as well as data acquisition, alarm detection and alarm notification.

Acquisition, alarm detection and alarm notification.

Process variables are controlled using time-proven algorithms

(mathematical calculations that perform specific functions).

These algorithms are contained in functional control blocks that are configured

by the field process engineer to implement the desired control strategy.

The versatility of the algorithms, combined with the variety of available FBMs,

provides control capabilities suitable for a wide range of process applications.

From simple feedback and cascade loops to highly complex feed-forward,

non-linear and complex characteristic control schemes,

a variety of control strategies can be easily implemented.

The FCM has a rugged extruded aluminium enclosure that provides physical protection for the circuitry.

Enclosures specifically designed for the installation of FBMs and FCMs provide varying degrees

of environmental protection for the FCM, up to harsh environments (Class G), in accordance with ISA Standard S71.04.

The FCM can be removed/replaced from the base plate without power failure.

six light-emitting diodes (LEDs) on the front of the FCM.

Six light-emitting diodes (LEDs) on the front of the FCM are used to indicate the status of

network activity with the modular fieldbus and fibre-optic link, as well as the operational status of the FCM.

Figure 1 shows an example of a redundant configuration where the baseboards

(containing the FCM) are connected point-to-point via fibre optic cable.

The cabling configuration shows a single fibre optic segment connecting two substrates.

However, up to three fibre segments can be used to connect four baseboards (maximum).

The maximum fibre cabling distance between any two base stations is 10 km (using FCM2F10s (RH916TQ)).

The total fibre optic cabling distance (all cable segments) between base stations does not exceed 20 km (10.42 miles).
