MOTOROLA MVME55006E-0163R - Motorola Industrial Controller

The I/O on the MVME162FX is connected to the VMEbus P2 connector.

The main board is connected via a P2 transition board and a cable connecting the transition board.

The MVME162FX supports the transition boards MVME712-12. MVME712-13.

MVME712M, MVME712A, MVME712AM, and MVME712B (referred to in this manual as MVME712x unless otherwise noted).

The MVME712x transition board provides configuration headers and industry standard connectors for I/O devices.

I/O connections to the serial ports on the MVME162FX are also made via two DB-25 front panel I/O connectors.

The MVME712 series transition boards are designed to support the MVME167 boards,

but can be used on the MVME162FX if some special precautions are taken.

(For more information, see the Serial Communications Interfaces section

of the MVME162FX Embedded Controller Installation and Use Manual).

These transition boards These transition boards provide configuration headers,

serial port drivers, and industry-standard connectors for I/O devices.

These transition boards provide configuration headers, serial port drivers,

and industry standard connectors for I/O devices.

Functional Features

- Optional Processor:

- 32 MHz MC68040 Enhanced 32-bit Microprocessor with 8KB Cache and MMU and FPU

- 25 MHz MC68LC040 Enhanced 32-bit Microprocessor with 8KB Cache and MMU

- A32/D64 VMEbus Master/Slave Interface with System Controller Function

- High performance DMA support for VMEbus D64 and local bus memory burst cycles

- 4. 8 or 16MB of shared DRAM

- 512KB SRAM with battery backup

- 1MB Flash for on-board monitor/debugger or user-installed firmware

- 8K x 8 NVRAM and time clock with battery backup

- Two serial communication ports, console port is EIA-232-D DCE, second port is user configurable to EIA-232-D/EIA-422 (V.36) DTE/DCE

- Four 16-bit or two 32-bit IndustryPack® ports, one DMA channel per port

- Six 32-bit timers (four without VMEbus) and watchdog timer

- Optional SCSI bus interface with 32-bit local bus burst DMA

- Optional Ethernet transceiver interface with 32-bit local bus DMA

- One 32-pin PLCC EPROM socket

- Four-stage requester, seven-stage interruptor, and seven-stage interrupt handler for VMEbus

- Remote reset/pause/status control functions

- On-board debugger and diagnostic firmware
