Prosoft MVI69E-GEC Generic ASCII Ethernet Communication Module

The MVI69E-GEC Generic ASCII Ethernet Interface module is

designed to allow CompactLogix™ / MicroLogix™ processors to

interface easily with ASCII devices using the TCP/IP protocol.

Compatible devices may be either ASCII instruments with built-in

Ethernet or Ethernet connection via a thin server to the existing

ASCII device.

Five servers and Clients are present on the module permitting both

the reception and transmission of data between the Rockwell

Automation processor and attached devices.

The MVI69E-GEC module is a powerful communication interface for

CompactLogix / MicroLogix processors. Developed under license

from Rockwell Automation, the module incorporates proprietary

backplane technology that enables powerful data access between

the module and the CompactLogix / MicroLogix processor.

Features

 Single-slot - 1769 backplane compatible

 The module is recognized as an Input/Output module and has access

to processor memory for data transfer between processor and module

 Ladder Logic is used for data transfer between module memory and

processor controller tags. A sample ladder file with AOI is included

 Configuration data obtained from configuration text file downloaded

to module

 Supports CompactLogix and MicroLogix 1500 LRP Controllers except

1769-QBFC1B, 1769-L16x, and 1769-L18x

DH+ to EtherNet/IP™

1/ The operating mode acts as a bridge between an EtherNet/IP and a DH+ network.

Programming terminals, and/or processors on an EtherNet/IP network can access legacy

processors on a DH+ network

Download to a PLC5 or SLC through RSLinx

Configured through web browser

Supports all DH+ baud rates (57.6. 115.2. and 230.4 K baud).

2/ The operating mode helps the communication between an Ethernet-Based processor

with legacy processors on a DH+ network.

Support gathering data without changing existing PLC or SLC hardware
