HITACHI LPA302A Control System Module

Hitachi Energy's FOX515H is a state-of-art utility multiplexer, scalable from DS0 up to

multiple STM-64. The FOX515H supports multiple rings for capacities up to STM-64.

and Ethernet over SDH for pushing packet data over TDM fibers.

Its non-blocking DXC’s allow traffic grooming at 64kbps-level as well as cross-connecting

at VC-12/VC-3/ VC-4.

The product you are looking for is not available anymore. For more information,

you can contact us by clicking on the Contact button at the bottom of the page.

FOX515H is a highly scalable device, which allows growing backbone capacities

from STM-1 up to STM-64 for the transport of TDM- as well as of Ethernet-traffic.

This very compact FOX-device provides extensive protection mechanisms such as

HW-protection for MPU and tributaries (two groups 1:N, N=1-5) and the full set

of traffic protection methods like MSP, SNCP and/or 2 / 4-fiber MS-SPring for

SDH-connections.

Synchronization view

• Provides an overview of paths and dependencies (synchronization map).

• Collects current synchronization timing source information from FOX515/512

or FOX615/612 network elements.

• Displays this data graphically for easy visualization

Performance Management

• Performance management oversees individual data channels’ quality within a network.

• Alarms are triggered if predefined threshold levels are exceeded.

• Facilitates network operators in maintaining high service quality for subscribers.

• Constant supervision ensures optimal performance.

• Performance data in network elements adheres to the ITU-T G.826 standard.

The fully redundant network element supports all SDH-traffic protection schemes

including 2/4-fibre MS-Spring. All optical ports are XFP / SFP based.

Fully integrated and managed boosters / preamplifiers / equalizers enable highly

flexible and reliable long-haul connections, without the need for additional external

devices. The robust mechanical and EMC-design including the distributed power

supply concept of FOX515H are optimized to cope with harsh environments which

are typical for utility applications. The mechanical, electrical and EMC / safety

performance of FOX515H is fully type-tested by an independent, certified Swiss

Test-lab. Most interfaces are provided with multirate SFP/XFP cages enabling each

individual port to have a different configuration with a wide variety of optical

wave-lengths for WDM, connectors and available ranges.
