GE IS215UCVEH2AB VMIVME-7614-132 350-007614-132C Single/Double Slot Controller

IS230PCAAH1B is a Core Analog I/O Module manufactured and designed

by General Electric as part of the Mark VIe Series used in distributed control systems.

A sizable amount of the analog signal I/O needed to run a gas turbine is provided

by the Core Analog (PCAA) module and related Core Analog (TCAS and TCAT) terminal board.

Thermocouple, 4-20 mA current loop, seismic, linear variable differential transformer

(LVDT) excitation and inputs, pulse rate, and servo coil outputs are all provided by PCAA and TCAT.

In simplex, dual, and TMR systems, PCAA is applicable.

To one, two, or three linked PCAA modules, a single TCAT terminal board fans signal inputs.

In addition to the terminals on PCAA and TCAT, a nearby JGPA board also has shield ground

and 24 V field power connectors.

The PCAA, however, does not care how an Ethernet connection is made and negotiates

correct functionality via either port. The network connection should match the connection

made to TCAT if TMR PCAA modules are present. For instance, cables to the TCAT

PR1 and PR2 connectors should be present on the PCAA module with the R IONet connection.

Verify that the JGPA shield wire terminals are grounded.

The JGPA shield ground connections are typically electrically connected to the sheet metal that the board is mounted on.

The ground path for the terminals is then provided by the mounting.

It may be necessary for some situations to specify a shield ground that is separate from the mounting sheet metal.

The JGPA is mounted in these applications utilizing hardware that separates the board from the sheet metal.

Between one or more JGPA terminals and the necessary shield ground

potential in these applications, a suitable ground wire must be provided.

Check the power and Ethernet status indicator lights after powering on the module using the P5 connector.
