GE 94-164136-001 Industrial Control Module

Multilin™ C30

Substation Hardened Programmable

Logic Controller

The Multilin C30 controller system is a substation hardened device designed to perform substation

control logic that can also expand the I/O capability of protection devices and replace existing SOE

recorders. The C30 provides fast and deterministic execution of programmable logic with I/O capabilities

far above an average protection relay.

Graphical programming tools, supported by a library of logic operators, make the C30 simple to use

and configure. Using high-speed peer-to-peer communications for inter-device messaging, the C30 can

also accept signals and commands from other protection and control devices at a fraction of the cost

of hard-wiring these signals.

AAA Server Support (Radius/LDAP)

Enables integration with centrally managed

authentication and accounting of all user

activities and uses modern industry best

practices and standards that meet and exceed

NERC CIP requirements for authentication and

password management.

Key Benefits

• Powerful and deterministic programmable logic suitable for creating most customized automated

substation control solutions

• Modular hardware architecture allowing for flexibility in the I/O configuration to support most bay

management applications

• Reduced bay or station wiring through the use of high-speed peer-to-peer communication for sending

and accepting control commands from other relays

• Simplified system integration and access to information through the use of multiple communication

options and protocols not found in industrial grade PLCs

• Advanced IEC 61850 Ed. 2 implementation, complete settings via SCL files and IEC 61850-9-2 process

bus solution enable resource and platform managing optimization and reduce cost of ownership

• Increased network availability via failover time reduced to zero through IEC® 62439-3 “PRP” support

• CyberSentry™ provides high-end cyber security aligned to industry standards and services (NERC® CIP,

AAA, Radius, RBAC, Syslog)

• Advanced fault and disturbance recording, including internal relay operating signals, eliminating the

need for external recording devices
