Modular TBX modules (IP20): Extensions

General

The modular TBX modules are composed of a base unit and an optional extension. The extension

is composed of the following elements:

 A protective cover for the base unit (1),

 A base unit (2) featuring Discrete and/or analog inputs and/or outputs.

 A removable terminal block (3) for direct connection of the sensors and/or preactuators to the

I/O. The necessary power supplies are also wired to the terminal block,

 A connection cable (4) for linking the communication module (see page 33) to the extension

module.

Physical Description

The TBX CBS 010 assembly comprises:

 A connection cable enabling the extension base unit to be connected to the communication

module.

 A cover, which is fixed to the extension base unit, protects the connector and gives the

extension module (base unit + cover) a similar size and shape to that of the base module.

 A self-adhesive label is used to label the channels 16 to 31.

To connect the extension module to the basic module, the connection cable between the 32

pin 1/2 DIN connector on the communication module and the 32-pin 1/2 DIN connector on the

extension base unit is first connected, and then the cover is placed over this base unit and fixed in

place.

TBX LEP020 and TBX LEP 030 communication modules

General

The TBX LEP 020 or TBX LEP 030 communication module enables communication with the PLC,

via the Fipio bus.

It is connected to the base unit to which it is fixed by a 32-pin male 1/2 DIN connector located in its

lower section. A 32 pin female 1/2 DIN connector, protected by a cover, is used to connect the

base unit for the extension.

NOTE: For a connection point comprising only the Discrete TBX modules, either a TBX LEP 020.

or a TBX LEP 030 module may be used.

For a connection point comprising analog TBX modules, it is obligatory to use the TBX LEP 030

module.

Accessories of TBX IP20 modules

Wiring accessories

To simplify wiring, the following accessories for wiring TBX IP20 distributed I/O modules are

proposed:

 A grounding strip connected to ground by the terminal, which enables all the protective

screening for sensors and/or preactuators to be connected to the local ground.

This accessory is sold in lots of 5. reference TBX GND 015.

The quick installation of this strip, (fixed to terminals 2 and 40 on the terminal block) means that,

although it is joined to the main terminal block, an additional connection level is formed. The

assembly can still be removed.

In addition, a laterally fixed terminal is used to connect the local ground and the metallic parts

of the product in order to provide permanent protection of the base units.

 An inter-terminal connecting comb is used to connect together several terminals at the same

voltage.

This accessory is sold in lots of 5. reference TBX RV 015.

They are designed so that 2 combs may be used in the same connection space, one on top of

the other. They are perforated so they can be cut to the correct length by the user, and can be

used for 2 to 9 terminals.

Insulation between the two combs installed one on top of the other is 2000 V AC.
