Honeywell 5SE1-12 Snap Action 5A 250V AC Micro Switch

Alarms

Up to four electromechanical alarm relays are available to activate external equipment

when preset alarm setpoints are reached. Each of the four alarms can be set to monitor

two independent setpoints. Each alarm setpoint can be either high or low alarm. The

alarm type can be selected to be either of the inputs, the Process Variable, Deviation,

Output, Shed from communications, PV rate of change, or to alarm on manual mode

activation or a Current Output Open failure. It can also be used as an On or Off event at

the beginning or end of a Ramp/Soak segment. An individual alarm hysteresis setting is

provided for each relay and these are configurable from 0 to 100% of range.

 Alarms can be configured as latching or non-latching. continued

 Alarm blocking is also available which allows start-up without alarm energized

Compatible Devices

 • UDC9000 Controllers

 Verified Device

 UDC9000 comprising:

 • 620-1200C

 • 620-0073C

 • Analog and Digital I/O

 • Allied Technology MC15 Ethernet Media Converter

 Caution: The programmer is responsible for knowing the addressing range permitted in the device to be attached.

Features

 3 Universal Analog Inputs (can be configured to act as one Universal and four High Level)

 ± 0.10% Analog Input Accuracy (can be Field Calibrated to ± 0.05%)

 16-bit Analog Input resolution typical

 Fast scanning rate (166ms)

 Up to 7 Analog and Digital Outputs

 4 Digital Inputs

 Two Math Functions, two Characterizers, one Polynomial equation and one Totalizer available

 Two Independent Loops or Cascade Loop

 Up to four 20-segment Setpoint Programs (can be concatenated to form two 40-segment Setpoint Programs)

 Ethernet TCP/IP with Email or RS-485 Modbus communication

 Infrared PC & Pocket PC configuration

 NEMA4X and IP66 front face protection

 Multilanguage prompts

 ¼ DIN Size

 Easily Field Upgradeable
