EATON XVS-430-10MPI-1-10 Touch Panel

The ATC-900 includes two styles, open or closed-transition, and

offers a variety of monitoring and control features such as selective

load shedding, remote load testing, and event logging/recording.

Flexibility is another important benefit, allowing field configurability

and expandability in the future with add-on accessory modules and

hardware. For retrofit applications, an upgrade kit is available from

the ATC-600/800 to the ATC-900.

Preliminary comments and safety precautions

This technical document is intended to cover most aspects associ

ated with the installation, application, operation, and maintenance

of the ATC-900. It is provided as a guide for authorized and qualified

personnel only in the selection and application of the ATC-900.

Please refer to the specific WARNING and CAUTION in Section 1.1.2

before proceeding.

If further information is required by the purchaser regarding a

particular installation, application, or maintenance activity, an Eaton

representative should be contacted.

Warranty and liability information

In no event will Eaton be responsible to

the purchaser or user in contract, in tort (including negligence),

strict liability or otherwise for any special, indirect, incidental or

consequential damage or loss whatsoever, including but not limited

to damage or loss of use of equipment, plant or power system,

cost of capital, loss of power, additional expenses in the use of

existing power facilities, or claims against the purchaser or user by

its customers resulting from the use of the information and descrip

tions contained herein. Analyze all aspects of the application, follow

applicable industry standards, and follow the information concerning

the product in the current product catalog and in any other materials.
