ABB WBPEEUS240011 Harmony Rack Input/Output

Bailey Infi 90 Sequence of Events Master Manufacturers ABB, Bailey Model(s)

ABB Bailey Infi 90, ABB Bailey Infi 90 and Net 90

Additional Information This is a kit that includes the INSEM01, INNIS01, and INTKM01 modules along with the associated termination units and cables.

Estimated Shipping Size Dimensions: 2.0" x 7.0" x 13.0" (5.1 cm x 17.8 cm x 33.0 cm)

Weight: 0 lbs 6.1 oz (0.2kg )

Tariff Code: 8538907080

Country of Origin: United States Ships from Webster NY, USA

Bailey Infi 90 Sequence of Events Master

Symphony Harmony

IndustrialIT System 800xA

Overview

Features and Benefits

■ Extending the Return-on-Investment

of Harmony Systems. New hardware

and software product releases increase

operating efficiency and extend the

life of installed systems. New products and programs make the decision

to evolve existing systems straightforward and easy.

■ System 800xA Extends Harmony

System Functionality to Achieve

Greater Productivity Gains. System

800xA extends the reach of traditional

automation systems. When integrated

with Harmony systems, productivity

gains necessary to succeed in todayís

business world are achieved.

The IOR810 has the following features:

- Selectable redundant or non-redundant configurations

- Supports the Sequence of Events (SOE) function of the S800 I/O subsystem.

- Ability to interface with the following types of I/O in the S800 I/O subsystem: basic AI/AO, basic DI (contact input), SOE DI, basic DO,

Pulse inputs, temperature device inputs (RTDs and thermocouples), intrinsically safe,

and redundant I/O Table 5 lists the S800 I/O modules that have been validated for use with the IOR810.

The IOR810 provides an alternative way to use the S800 I/O with Sequence of Events (SOE) functionality.

The accuracy of the SOE timestamps is determined by the specifications of each S800 SOE digital input module type.

The IOR810 is the interface between the HN800 I/O bus (electrical or fibre optic) and the existing S800 I/O module bus (fibre optic only).

The core function of the IOR810 is to scan the S800 I/O modules and provide information to the Symphony Plus controller via the HN800.

The IOR810 connects and scans up to seven S800 cluster modems over the fibre module bus.

Each cluster modem can support up to 12 S800 I/O modules.

The distance between the IOR810 and the Symphony Plus controller is up to 30 metres if connected via the electrical HN800 bus;

If connected via a fibre optic HN800 bus, the distance between the IOR810 and the Symphony Plus

controller is up to 3000m using RFO810 repeaters.

If using plastic fibre optic cables, the maximum distance of the fibre optic modular bus between the

IOR810 and the S800 cluster modem or between two cluster modems in a daisy chain is 15 metres.
