Honeywell TR40-CO2 Sylk Wall Module Sensor

Enjoy reduced labor and material costs when you go wireless with Honeywell TR20

wireless sensors. In both new and retrofit applications, the TR20 family integrates

seamlessly with a wide range of controllers, adding fully programmable building

automation control — without the hassles and costs of wires and conduits. Labor

time is greatly reduced, and sensor relocation is now a breeze. From vintage hotels

and historical buildings to modern office facilities, the point-to-point solution of TR20

wireless wall modules provides precision control that saves costs while preserving

the building’s appearance.

Add the point-to-point solution of TR20 wireless wall modules

and receivers to the flexible programming of many Honeywell

controllers, and you’ll meet the demand for energy-efficient,

accurate control without the time and cost of wiring. You’ll

save time and money while improving performance, and that’s

outstanding for everyone’s bottom line.

Set jumpers and scale sensors.

It is essential to set physical jumper Honeywell current

sensors. You need to match this scaling, either via LCBS

Connect wall module or LCBS Connect Web UI. If you

don’t, CT output will read incorrectly.

Set differential pressure sensors, set switches.

Make sure that you set the physical switches on the

Honeywell P7640 device to measure 0 to 2.5 inches of

water column. Please check this setting on the sensor.

Further, you will need polyethylene tubing running to the

high pressure side of the filter. Please refer to installation

information if you need help determining proper poly tube

positioning relating to the filter.

If you wait to do the research during general system

installation, you will find that your installation time will be

unacceptable to you. Use the “Introduction to LCBS

Connect — Information Technology Background” as a

resource tool with your customers in advance of your

general installation.

The LCBS Connect™ controller and wall module

combination is designed to control constant volume

air handling units and heat pumps. With the embedded

control logic and integral temperature humidity sensors,

it controls the space temperature in a given zone by

regulating the heating and cooling equipment to deliver

conditioned air to that space. The LCBS Connect gateway

serves as the communication device between a building

site and the Honeywell cloud, providing contractors with

a way to remotely monitor, control, and configure

Honeywell building controllers from Honeywell’s LCBS website.
