ALSTOM RDSP1 – BOARD FOR ADJUSTING DIGITAL SIGNAL PROCESSES

Innovative Concepts

To satisfy the diverse requirements of its extensive range of available speed drives,

ALSTOM has a range of controllers available from 16-bit, fixed point, embedded

software versions to 32-bit floating point versions.

ALSTOM recently developed a new power electronic controller family (PEC) that ranges

from single card units (standard or advanced) for products and small systems to modular,

rack based arrangements, suitable for the most complex applications.

ALSTOM has embarked on a programme to make the PEC family available for all of its solutions.

The advantages that the PEC family will bring to the user are numerous, some features are highlighted below.

Recent innovations in drive solutions include:

a new type of electric propulsion that mounts the motor in an under-ship pod;

a 19MVA, 4.2kV an IGBT propulsion converter and motor for electric warship;

100MVA converters for pumped storage systems;

and 15MVA, 50Hz, three phase to single phase traction supply converters with

Active Energy Management.

The VP32502X ALSTOM Single Board Processor is a high-performance industrial

processor designed for advanced automation and control systems. Built with

robust architecture, it provides reliable and efficient data processing capabilities

in demanding environments. The board is engineered for integration into ALSTOM

systems, enabling precise control and monitoring of complex industrial processes.

Its compact design and powerful processing power ensure seamless communication

between various components in automation networks. Ideal for applications requiring

high-speed computation and real-time data management, the VP32502Xensures smooth

system performance and enhances operational efficiency in industrial settings.

Common Programming Tools

for all Drives and Automation

The new PEC family provides a single architecture for all drives in which the essential

features are implemented using common technologies, including:

• Pentium class processor operating at 32-bit with floating point calculations

• Common operating system, used by both drives and automation

• IEC 61131-3 programming with Function Block Diagram as the core language

• Common control structure built from a common library of function blocks

• Common programming tools

• Common HMI systems

• Communication interfaces including all popular fieldbusses

• All hardware, software and communication interfaces based upon industry standards

Alstom   MICROREC K4.1.  Series：

AMS42 - POWER SUPPLY BOARD

IRVI20 - REGULATION INTERFACE BOARD

MDEX1 – EXCITATION CURRENT MEASUREMENT AND CALIBRATION BOARD

RDSP1 – BOARD FOR ADJUSTING DIGITAL SIGNAL PROCESSES

ESVI1 - INPUT/OUTPUT BOARD FOR CURRENT AND VOLTAGE SIGNALS

CPRM1 - SINGLE-PHASE POWER REGULATION BOARD

MCRI1 - MODULE BOARD FOR SETTING SETTINGS AND CURRENT REGULATION

ARTN1 - DIGITAL INDICATION BOARD FOR VOLTAGE REGULATION

FRTN2 - BOARD OF DIGITAL INDICATION OF VOLTAGE REGULATION

E64L1- LOGIC INFORMATION ACQUISITION BOARD

BCEL2 - TERMINAL BOARD FOR 12 LOGIC INPUT SIGNALS

BCEA1 - TERMINAL BOARD OF 8 ANALOGUE INPUT SIGNALS

BCSR1 - TERMINAL BOARD OF 8 LOGIC OUTPUT SIGNALS
