ABB NCIS02 Control I/O Module

Control I/O Module Manufacturers ABB, Bailey Model(s)

ABB Bailey Infi 90 and Net 90, ABB Bailey Net 90

Estimated Shipping Size Dimensions: 7.0" x 2.0" x 13.0" (17.8 cm x 5.1 cm x 33.0 cm)

Weight: 0 lbs 12.0 oz (0.3kg )

Tariff Code: 8538907080

Country of Origin: United States Ships from Webster NY, USA

Control I/O Module

The S100 I/O process interface modules for Advant Controller 400 series process controllers come with connection units

simplifying cable termination and keeping noise and destructive spikes away from the central electronics.

S100 I/O is the central process interface for Advant Controller 400 series process controllers.

Thanks to built-in cablemarshalling facilities and parallel communication with the host controller,

it is the right choice for centralized I/O systems and high-speed applications.

The range of process I/O modules is complete, consisting of general purpose digital and analog

inputs and outputs and special interfaces for specialtasks. These specials include pulse counting,

frequency measuring, positioning, motor speed control and communication with other controllers.

All I/O modules provide simple interfacing, accurate -yet fast - control, and easy integration of individual

loops into a comprehensive plant-wide control and supervision system.

The interface modules connect to the process through screw terminals on connection units normally installed inside, at the back of the cabinet.

This solution keeps noise and destructive voltage spikes away from the central electronics and provides a neat and tidy process interface that is easy to maintain.

Physical Features and Interfaces

Interface layout and types: A wide range of interfaces are available, including digital inputs, digital outputs, analogue inputs and analogue outputs.

Digital input interfaces are used to connect digital sensors (e.g. limit switches, proximity switches) and digital signal sources,

and digital output interfaces are used to control digital actuators (e.g. relays, indicator lights).

Analogue input interfaces are used to connect analogue sensors (e.g. temperature sensors, pressure sensors)

and analogue output interfaces are used to control analogue actuators (e.g. control valves, frequency converters).

The interface type may be a pin-type interface or a screw terminal interface, which facilitates the connection of different types of wires.

Physical design: The design is generally compact and easy to install in limited spaces such as control cabinets or equipment racks.

The housing is usually made of metal or high-strength engineering plastics, with good impact resistance and heat dissipation performance.

In terms of installation, it may support rail mounting or screw-fixed installation,

which is convenient for users to choose according to the actual installation environment and requirements.

The internal circuit layout is reasonable, taking into account the electromagnetic compatibility and heat dissipation requirements to ensure long-term stable operation.
