Eaton F11-YK2 Fieldbus F11 Power Hub with fieldbus cables

Crouse-Hinds series MTL Megablock™ is a DIN-rail mounted passive hub

designed for use in FOUNDATION™ fieldbus H1 and Profibus PA networks.

Megablocks minimize hand wiring and allow individual devices to be added

to and removed from the segment without disrupting network communication.

The SpurGuard™ option provides short circuit protection for the segment.

Hazardous area approvals permit installation in a variety of configurations in

Zone 1 or 2 and Division 1 or 2. Within Zone 2 or Division 2. Megablocks may

be installed as part of non-sparking (non-arcing) or energy-limited

(non-incendive) circuits.

• F2xx-IS models: Intrinsically Safe Megablocks for Zone 1 applications

• F2xx-XE models: Megablocks for Zone/Div 1 applications

• F300 models: Megablocks for Safe Area and Zone/Div 2 applications

Certifications and compliances

• For a complete listing of certification and approvals across our MTL Megablock range,

download the product datasheets in the resources section of this family page.

Design features

• A green power LED on each unit indicates whether at least 9V dc is present.

• Available in two, four, eight, ten and twelve drop versions

• Multiple Megablocks are easily wired to one another to allow larger segments to be

constructed

• Choice of rising cage-clamp screw terminal or spring clamp type connections simplifies

commissioning and maintenance

• Available with built-in SpurGuard™ protectors that prevent a short circuit in any of the

individual transmitters or spur

cable runs from bringing the entire fieldbus segment down

• A red LED near each spur connection indicates that a spur is shorted and is in

“over-current” mode

Standard materials

• Housing:  Polycarbonate
