Advantest AGILENT E8001-66412 Backplane Control Board

The R6552 Series is a digital multimeter designed for system or bench use with the maximum display of 319999.

featuring GPIB and RS232 interfaces with full remote control capability.

It is capable of measuring DC voltage/current, AC voltage/ current, 4- or 2-wire resistance,

low/power 4- or 2-wire resistance, (AC+DC) AC voltage/current, frequencies, and diodes.

ADVANTEST's unique multi-slope integral A/D conversion method ensures high speed and high precision measurements.

The AC voltage/current measurement uses the true-RMS (true effective value) method while

the (AC+DC) AC voltage/current measurement allows measurement of a true effective

value of the distortion wave including the DC components.

Synchronization available up to 325 GHz

■ Resolution bandwidth (RBW):

10 Hz to 10 MHz, 5MHz (analog)

1 Hz to 100 Hz (digital)

■ Wide dynamic range:-145dBc/Hz (2GHz band, typ.)

70dB or better for W-CDMA ACP measurement  (5MHz offset, typ.)

■ 1µs fast zero-span sweep

■ Simplified, Automated measurements for mobile communications

■ Digital modulation analysis options for 1G, 2G, and 3rd

Generation : PHS, PDC, IS-136. GSM, DECT, EDGE, GPRS IS-95. W-CDMA/3GPP, cdma2000. Bluetooth

The Advantest R3267 spectrum analyzers provide accurate, repeatable measurements of high-quality

digital signals in the 2GHz band ± within 1% frequency span accuracy and -154dBc/Hz dynamic range (typical).

In addition, its 10Hz to 10MHz resolution band with filters is capable of performing 70dB (typical, 5MHz offset)

 ACP measurements over W-CDMA, making it ideal for testing wideband signals.

Finally, the R3267 has a frequency range of 100Hz to 8GHz, allowing even high-frequency systems to be fully measured.

The front panel of the R3267 consists of the Display section, Power Switch/Connector section,

Floppy Disk Drive section, Measurement section, Marker section, Save/Recall section, Display Control section,

ENTRY section, REMOTE section, Control section, and Option section.

Remove dust from the exterior of the R3267 by wiping or brushing the surface with a soft cloth or small brush.

Use a brush to remove dirt from around the panel keys. Hardened dirt can be removed with

a cloth that has been soaked in water containing a mild detergent.

Normally, cleaning the display filter from the front is sufficient. However, if the inside of the filter or the LCD surface is dirty,

you can detach the screen filter from the R3267 series by removing the two screws on the front and pulling

forward on the right part of the filter. Clean the filter with a soft close.
