MOOG D136-003-005 Interfaces of Ruggedized Motion Controller
❤ Add to collection

MOOG D136-003-005 Interfaces of Ruggedized Motion Controller

+86-18144100983
kongjiangauto@163.com
wind, petroleum, chemical, natural gas, Marine, mining, aviation, electronics, steel, nuclear power, electric power, coking, air separation and so on
PLC, DCS, servo, analog, Ethernet, digital, redundant module, tension system, excitation, generator management, human-machine interface, detection card, sensor, AC drive, etc
U.S.＄9477.00
U.S.＄5727.00
Weight：3.300KG
Quantity：
(Inventory: 3)
Buy now
Add to cart
Product parameters
  • Tell:+86-18144100983
  • email:kongjiangauto@163.com
  • Application:wind/ petroleum/ chemical/ natural gas/ Marine/ mining/ aviation/ electronics/ steel/ nuclear power/ electric power/ coking/ air separation and so on
  • Series:PLC/ DCS/ servo/ analog/ Ethernet/ digital/ redundant module/ tension system/ excitation/ generator management/ human-machine interface/ detection card/ sensor/ AC drive/ etc
Feature

Installation

PlacementA horizontal DIN rail, mounted on the vertical rear surface of an industrial steel enclosure,

is the intended method of mounting.

The rail release clip of the G122-829A001 should face down,

so the front panel and terminal identifications are readable and so the internal electronics receive a cooling airflow.

These Application Notes are a guide to applying the G122-829A001 P-I Servoamplifier.

These Application Notes can be used to:

 Determine the closed loop structure for your application.

 Select the G122-829A001 for your application. Refer also to data sheet G122-829.

 Use these Application Notes to determine your system configuration.

  Draw your wiring diagram.

 Install and commission your system.

Aspects, such as hydraulic design, actuator selection, feedback transducer selection,

performance estimation, etc. are not covered by these Application Notes.

The G122-202 Application Notes (part no C31015) cover some of these aspects.

Moog Application Engineers can provide more detailed assistance, if required.

The G122-829A001 emits radiation well below the level called for in its CE mark test.

Therefore, no special precautions are required for suppression of emissions.

However, immunity from external interfering radiation is dependent on careful wiring techniques.

The accepted method is to use screened cables for all connections and to radially terminate the cable screens,

in an appropriate grounded cable gland, at the point of entry into the industrial steel enclosure.

If this is not possible, chassis ground screw terminals are provided on the G122-829A001.

Exposed wires should be kept to a minimum length.

Connect the screens at both ends of the cable to chassis ground.
