Bently CBBLO026 Carrying casefor the kit

Machinery shutdown functionality of the 3701/55 ADAPT ESD system is

actuated by TMR relay output modules. Each relay output module has five

relays with a level of configurability that accommodates a variety of applications

and requirements. Four of the five relays in each module are used to annunciate

system logic. The remaining relay reflects the OK/NOTOK status of the associated

protection path. The Bently Nevada Monitor Configuration software provides a

graphical interface to configure relay logic.

The state of each relay is determined by the system inputs and configured

system logic in conjunction with thecontrol state of the relay. Relay control states

depend on the application, and may be set as normally energized/de-energized

and independent one-out-of-one, (1oo1), voting or TMR two-out-of-three,

(2oo3), voting. Each CPU module in the system has two, internally powered,

4-20 mA recorder outputs controlled by the full-scale speed set by the user through

the Monitor Configuration software.

Compliance

The 3701/55 ESD complies with most applicable technical regulations and standards.

• North American general safety, CSA certified

• CE, Low Voltage and Electro-Magnetic Compatibility

• Functional Safety certification (SIL)

• CE, Machinery Directive

• North American, Hazardous Area certification, CSA certified

• European ATEX and IECEx Hazardous Area certification pending

The 3500 system also protects your machines and processes against false-trips that

could bring your operation down for no reason, resulting in a costly outage or loss of production.

When connected with our System 1† software, it also provides continuous condition

monitoring information for use in a proactive maintenance program.

The 3500 system incorporates the industry’s most extensive selection of machinery

measurement parameters combined with software configuration for virtually

all machinery monitoring scenarios.

GE WES5120 2340-21005 DC Digital Input/Output (I/O) module

GE V7768-320000 3509301007768-320000A0 Gas turbine control module

GE UCSC H1 IS420UCSCH1A-B first quad-core controller

GE UCSC H1 IS420UCSCH1A-F-VO.1-A first quad-core controller

Bently 108M4045 SCOUT quick start guide

Bently PLUS0230 CategoryA power plug

Bently CBCC0027 or138M7748 Triple BNC adapter

Bently CBTB0278 SCOUT instrument

Bently 108M4044 AC power adapter

GE WES13-3 5167-0001-0210 Control Board Module

GE WES5120 2340-21003 DC sinking input module

Bently CBVB0032 carrying bag

Bently 113M5585 Accelerometermagnetic base

Bently MVBX0250 Reference_Guide
