Parker 6K4 Power Controller by COMPUMOTOR

This reduces inventory requirements and simplifies the ordering process,

making it easier for users to select and use the right servo drive for their needs.

In summary, the Parker C3S063V2F12I31T11M00 Compax3S servo drive

features a modular design, compatibility with multiple safety standards,

compliance with a number of international standards, compact structure,

and wide applicability, and other features and advantages.

These characteristics make it have a wide range of applications in industrial

automation, machinery manufacturing and other fields.

The Compax3S servo drive is a powerful and flexible device with a number of significant

features and advantages that enable it to perform well in a variety of applications.

The following are the main features and advantages of the Compax3S servo drive:

Compact structural design: Compax3S servo drives feature a compact structural design

that significantly reduces the size of the device and system, thus saving valuable space.

This design not only optimises the performance of the device,

but also makes installation and maintenance easier and more convenient.

Multiple interfaces and communication protocols: Compax3S servo drives provide a variety

of interfaces and communication protocols.

Features

The VMM0604 has 6 general purpose inputs that can be configured as active

high or active low signals.

In addition, they can be used to read analog voltages or as 6 frequency inputs

(2 AC-coupled and 4 DC-coupled).

The VMM0604 has 4 high voltage side outputs with a maximum PWM frequency

of 500 Hz and 4 low voltage side outputs with current detection.

The outputs can drive any type of vehicle load, including relays, solenoids, fans,

and more.

The system meets the stringent SAE J1455/EP455 environmental standards and

advances multiplexing technology with enhanced diagnostic capabilities and

Windows-based ladder logic programming.

The unit can be used alone or in conjunction with other multiplexing modules.

The multiplexing system is designed to simplify and reduce troubleshooting,

maintenance and documentation time for electrical systems.

The modules are self-programmable and feature LED status indicators that show

the status of inputs, outputs, power supplies, and network activity.

Reliability

The VMM0604 continuously monitors its eight outputs for fault information.

Faults detected include short circuits (ground or power), overcurrents, and open

loads. The VMM0604 allows the outputs to protect themselves electronically,

thus allowing the system to reduce the number of fuses.

In the event of a fault, the device will disable the output where the fault occurred.

The VMM0604 has 12 red LED diagnostic indicators that can be used to display

the status of inputs, outputs, power supplies, and the Controller Area Network

(CAN). On-board diagnostics allow for easy troubleshooting, and the auto-programmable

module saves time and maintenance costs by keeping module and program inventory

to a minimum. VMM users appreciate the module's rugged design as well as the

stringent industry environmental requirements and communications (SAE J1939)

standards. All of these features make the controller easy to integrate into any on-or

off-highway vehicle.
