Bently 108M3239 SCOUT100-Extwo-channel portable datacollector

The evolution of our accelerometer sensors, velocity-sensing tools, pressure sensors,

and vibration sensors can be traced back to our velocity sensors.

Inputs to the system are processed using three CPU modules to provide

triple modular redundancy (TMR). Each CPU processing module processes

two unique speed input channels, for a total of six speed channels for

the system. The processing modules also monitor an array of 32 discrete (DI)

and process variable (PV) signal inputs. Twelve channels of this input signal

array may be configured either as discrete inputs or 4-20 mA analog inputs.

Remaining channels in the array are reserved for discrete input signals only.

The ADAPT ESD system can drive 12 independent trip relays. Of the 12 relays,

six of these signals can optionally be configured for two-out-of-three, (2oo3), voting.

In the 2oo3 arrangement, the system activates a relay only when any two of the three

CPU modules drive to trip. In independent mode, or one-out-of-one voting, any single

CPU that drives to trip will cause an assigned relay to activate on the corresponding

output card. For the highest safety, the system should be configured in “de energize

to trip”, or “normally energized” mode so that loss of power will not result in a machine

running unmonitored.

The 3701/55 Emergency Shutdown Device, (ADAPT ESD) is a safety PLC

with a graphical logic programming interface and integrated overspeed detection.

ADAPT ESD is designed for emergency shutdown of rotating machinery such as

steam, gas, and hydro turbines, expanders, and other process equipment.

ADAPT ESD is a compact, standalone, triple-redundant, safety shutdown device

that is designed to meet a broad range of user scenarios and applications.

The design offers an electrical and mechanical package with attention toreliability

and availability as well as extensive self diagnostics and compliance to industry standards.

Bently 108M4044 AC power adapter

Bently CABB0560 BNC to BNC Cable,1meter

Bently 110M8172-012 USB data transfer cable

Bently CABUO213 Transducer cable

Bently 108M4045 SCOUT quick start guide

Bently CBCC0027 or138M7748 Triple BNC adapter

Bently CBTB0278 SCOUT instrument

Bently CBVB0032 carrying bag

Bently 113M5585 Accelerometermagnetic base

Bently MVBX0250 Reference_Guide

Bently 109M2384-01 Neck strap with SensorKeeper

Bently PLUS0230 USA/Canada - CategoryA power plug

Bently PLSAO241 South Africa/India -Category D power plug

Bently PLAU0228 Australia/New Zealand /China - Category Mpower plug

Bently PLHK0245 Hong Kong/UK Category-G power plug

Bently PLEU0229 Europe - Category Cpower plug
