Foxboro P0973JN 24-PORT FIBER MANAGED SWITCH

OVERVIEW

The 24-Port Fiber managed switch (P0973JN)

provides 24 100Base-FX ports with MT-RJ

connectors, two fixed 10/100/1000 ports and two

1000Base-X uplink (ISL) Gigabit (SFP) ports.

The two 1000Base-X uplink (ISL) Gigabit (SFP) ports

can be populated with Mini-GBIC uplink (ISL)

connector modules listed in Table 4.

The switch allows high-performance, full-featured

layer-2 Ethernet switching in small to medium-sized

network applications, as well as high-performance

direct end-station connectivity.

FEATURES

The 24-Port Fiber managed switch features:

 24 ports of 100Base-FX

 Two fixed RJ-45 10/100/1000 ports, configurable

for 100Base-Tx or 1000Base-TX for devices or

1000Base-TX for (ISL) uplink ports

 Two 1000Base-X uplink Gigabit (SFP) ports

 MT-RJ connectors on switch ports

 Full-duplex operation

 Supports VLAN configurations

 Configuration tasks through a local console port,

and monitoring through any SNMP/RMON based

management application.

 Shelf, desk, or 19-inch rack mounting

 Port mirroring technology and diagnostics that

allow local network traffic to be redirected to an

external probe for detailed analysis

 When installed with the optional redundant power

supply, there is no single point of failure due to

power disruptions.

NOTE

Two separate branch circuits are required for

redundant power.

OPTIONAL REDUNDANT POWER SUPPLY

Refer to “P0973JX REDUNDANT POWER SUPPLY”

on page 19.

UPLINK/SWITCH INTERFACES

Table 3 lists the 24-Port Fiber managed switch and

the MGBIC modules that can be added to the

switch. The MGBIC modules are added to specific

SFP ports to provide connectivity for ISL ports.
