Prosoft ILX69-PBS PROFIBUS DPV1 Slave for CompactLogix

From:ProSoft | author:Mr.Chen | Time :2026-04-02 | 83 view: | 🔊 Click to read aloud ❚❚ ▶ | Share:

The ILX69 PROFIBUS Slave module is an in-chassis PROFIBUS DPV1

Slave for CompactLogix, supporting cyclic PROFIBUS I/O data and

acyclic messaging. Explicit ladder logic CIP message blocks provide

slave status diagnostic data and the ability for acyclic messaging.

The ILX69 interface appears to the CompactLogix controller as a

standard I/O module allowing it to be configured via Studio/RSLogix™

5000.  The cyclic PROFIBUS I/O data can be configured in

Studio/RSLogix™ 5000. or configuration can be transferred from the

Master to the slave module. The Ethernet interface allows for remote

diagnostic and troubleshooting.  Complete program examples for simple

and quick start-up are available.

Features

 Rockwell Automation Encompass Approved

 PI Certified

 Remote diagnostics via Ethernet

 Supports DPV1 Acyclic Messaging

 Field-tested with multiple PROFIBUS Masters from multiple vendors

 AOP provided to allow for seamless integration to Studio 5000 and RSLogix 5000

 Video setup tutorial provided on www.prosoft-technology.com
