Mersen NH fuse-links gBat 1000V-1500V DC

From: Mersen | author:Mr.Chen | Time :2025-09-19 | 18 view: | Share:

FEATURES & BENEFITS

•  Design for DC applications

•  Full range breaking capacity

•  Low watt losses

•  Minimum breaking capacity 2IN

•  High cycling performance

•  High interrupting rating 150kA

APPLICATIONS

•  Electrical energy storage

•  Battery storage system

•  Line protection between battery

system and DC/DC converter or

battery inverter

•  DC grid protection

STANDARDS

• IEC 60269-7

• UL 248-13

• RoHS compliance

SPECIAL PURPOSE FUSES

GBAT FUSES FOR BATTERY ENERGY SYSTEMS

Mersen NH gBat fuse series was engineered specifically for protection

of battery systems. They offer full range protection and can protect

very small over currents as well as DC fault current up to 150kA

at max L/R 3ms. The NH gBat fuses serie covers various ratings in

1000VDC with NH1 and NH2 sizes, and in 1500VDC with NH1XL,

NH2XL and NH3L. They are of the gBat type that comply with new

IEC 60269-7 standard for Battery protection. They are available with

bolted type blades for direct mounting, or with plain blades.

TECHNICAL DATA OVERVIEW
