KEBA c-line Drives Economical positioning inverters

Allrounder for machine automation

The c-line family offers the right device series for practically all drive tasks

and motor variants. The basis of all drive controllers is identical.

Fast installation and smooth commissioning with preset motion solutions,

even with third-party motors, is a matter of course.

Flexible adaptations to the motion task are possible with the PLC without

additional costs. The integrated CANopen field bus and the wide range of

options ensure perfect integration into the automation solution.

Your benefits at a glance

• Wide power range (2 A-210 A, 375 W-110 kW)

• Wide mains voltage range (24 V-48 V DC, 1x230 V AC, 3x400V AC)

• Closed- or open-loop motor operation and device variants

• Integrated mains filter and 24 V supply

• STO safety technology

Unlimited motion

Optimized for positioning, speed- or torque-controlled operation is also possible

as an alternative. Preset versatile motion solutions with axis-internal profile

generation facilitate commissioning.

• Motion block table with intelligent follow-up job logic

• CANopen drive profiles according to DS402

• Position- or speed -synchronous electronic gear

• Path optimized rotary table operation

• Freely programmable motion profiles with the PLC

• Jog and homing mode

Features

The c-line Drives offer hardware and software solutions tailored to your application

as well as partnership-based services.

CANopen for free

In accordance with the motion profile DS402. the drive is parameterized and the

operating modes are controlled. Access to all data allows comprehensive machine

and drive diagnostics.

Precise motor control

The control technology also compensates for cogging and friction torques as well as

spindle pitch errors. In addition, filters for damping mechanical vibrations can be

parameterized.

Integrated mains filter

The mains filter is already integrated at the factory to comply with legal standards.

This also reduces the number of components in the control cabinet and simplifies installation.

System-Partnership

Professional project management is an important component for mutual success,

so that you stay on time and within budget. The faster the "time to market" the better.
