ICS TRIPLEX T8312 Trusted TMR Expander Interface Adapter Unit

From:ICS TRIPLEX | author:Mr.Chen | Time :2026-03-24 | 3 view: | 🔊 Click to read aloud ❚❚ ▶ | Share:

Trusted TMR Expander Interface Adapter Unit

Product Overview

This document provides general information for the Trusted® Triple Modular Redundant (TMR)

Expander Interface Adapter Unit T8312. Two versions of the Unit are available; one providing

inter-connection between the Trusted Expander Interface Modules in the Controller Chassis and

four Expander Chassis (T8312-4), and the other providing inter-connection to seven Expander

Chassis (T8312-7).

Features:

• Allows easy inter-connection of Controller and Expander Chassis.

• Unit is fully shielded for Electro-Magnetic Compatibility (EMC).

• Version available for smaller Trusted Systems – up to four Expander Chassis.

• Locking connectors for increased reliability.

Description

The Trusted Expander Interface Adapter Unit T8312 comprises four, or seven 12-pin ODU

connectors (dependent on type of Unit), a printed circuit board (PCB), a 96-way C type

connector which plugs into a double 96-way connector assembly designed to be connected

to the Trusted Expander Interface Modules resident in the Controller Chassis. The Unit is

contained within a metal enclosure and is designed to be clipped onto the Controller Chassis

rear connectors. A release button is provided to enable the Unit to be disconnected.
