Kollmorgen S700 Digital Servo Drive

The S700 is a digital servo drive with extended functionality that is ideal fo

complex drive tasks. It incorporates onboard Ethernet connectivity for use

 with EtherCAT® and SynqNet™, and the optional MMC memory card enables

parameter records and firmware to be easily backed up in the field.

A Safe Torque Off function is standard. Single Cable feedback with both SFD3

and Hiperface DSL is also supported.

Features

• CE, UL, TÜV safety tested

• Operation directly from grounded 110 to 480 VAC, 1 or 3-phase, 50 to 60 Hz lines

• Models with maximum continuous output current from 1.5 to 72 Amps RMS/phase

• Safe Torque Off (STO) function onboard

• EtherCAT® and CANopen bus communication onboard

• Legacy bus support including PROFINET, DeviceNet, PROFIBUS DP, SERCOS II and RS232

• Single Cable Feedback SFD3 and Hiperface DSL

• Slot for MMC memory card for backup and copy of parameters and firmware

• Optimized resolver interface

• Autotuning

• Cogging suppression

• Fastest feedback evaluation on the market

Benefits

• High-speed current, speed and position control result in higher machine cycle rates

• IEC 61131 macro programming language inside makes motion flexible

• Multi-interface and multi-feedback features provide compatibility with all standard

controllers and feedback systems, reducing the need to stock multiple drive types

• Onboard EMC filters and integrated power supply and brake resistor enable smaller

switchgear cabinets

• Memory card for parameter and firmware updates, autotuning features and connectors

for all connections facilitate faster setup
