Kollmorgen S600 Series of Digital Servo Drives

The S600 Series of digital servo drives operates directly from 230 to 480 VAC

lines and provides output current of1.5 to 20 Amps RMS/phase, continuous.

Intelligent positioning capabilities include speed profiles, register control,

jolt limiting, daisy-chained tasks, absolute and relative tasks, and several types

of reference traverses. These drives are supported for existing customers only.

For new applications, please contact your Kollmorgen team for the best product fit.

Features

• CE, UL, cUL

• Directly on grounded 3~ mains, 230V ... 480V AC

• Output current 1.5A to 20A

• Braking resistor integrated up to 20A

• Mains filter integrated up to 20A, all shield connections directly at the amplifier

• When using the servo amplifiers in residential areas, this product may cause

high-frequency interference. Additional filtering has to be provided by the user.

• Fits up to 20 A in 300 mm switch cabinets

• Operation via PC with setup software

• Interfaces for stepper motor control, master-slave operation, electronic gearing integrated

• Position controller with memory for 255 motion blocks integrated.

Intelligent positioning:

 speed profiles

 registration mark control

 jolt limiting

 chained motion tasks

 absolute and relative positioning

 various homing modes

• Encoder emulation selectable incremental or absolute

• Multi Feedback System:

• Resolver up to 36-pole

• ComCoder

• Incremental or Sine Encoder with Hall

• Sine Encoder with EnDat/HIPERFACE/BISS

• Sine Encoder without data track

• Incremental Encoder AquadB
