Rexroth R901342038 HM20-21/315-F-C13-0.50 Pressure sensors

From:Rexroth | author:Mr.Chen | Time :2024-10-23 | 255 view: | Share:

Description

The Bosch Rexroth HM 20-2X/315-F-C13-05-N (R901342038) is a high-precision pressure

transducer designed for monitoring and controlling hydraulic pressures within a wide range of applications.

This sensor is capable of measuring pressures with ranges up to 600 bar,

making it suitable for various demanding environments where accurate pressure readings are critical.

The transducer features a thin film measuring cell and components that come into contact with

media are constructed from stainless steel, ensuring durability and compatibility with a variety of fluids.

With its excellent non-repeatability of less than 0.1% and an accuracy class of 0.5,

the HM 20-2X/315-F-C13-05-N provides reliable and precise measurements essential for maintaining system performance and safety.

The device also boasts operational safety features including high bursting pressure capacity,

reversed polarity protection, overvoltage protection, and short-circuit protection.

This model operates within an extensive temperature range, ensuring consistent performance under varying environmental conditions.

Additionally, it has received marine approval DNVGL for all variants with current output,

which attests to its robustness and suitability for maritime applications.

The component series X to which this transducer belongs indicates

that it is part of a line designed to handle maximum operating pressures of up to 315 bar.

It offers pressure ratings at several intervals including 100, 160, 250, 315, 400, 600 bar etc.,

providing flexibility for integration into different hydraulic systems. Furthermore,

the HM 20-2X/315-F-C13-05-N is cULus-listed demonstrating compliance with

North American safety standards and regulations for industrial control equipment.

Features

Measuring pressures in hydraulic systems 8 measurement ranges up to 630 bar Sensor with

thin film measuring cell Components that are in contact with the media are made of stainless

steel Operational safety due to high bursting pressure, reversed polarity,

overvoltage and short-circuit protection Accuracy class 0.5 Excellent non-repeatability

< 0.05 % Wide operating temperature range –40 ... +85 °C Marine approval DNV-GL for all variants with current output.
