Autronica Mimic cabinet BUR-200, for maritime installations

Features

 Cabinet including 1 Mimic Driver BUR-200 and

16 programmable relays

 1 Mimic Driver is capable of driving 32 current

limited LEDs

 A Mimic Driver is provided with 8 standard

monitored inputs

 A maximum of 8 Mimic Drivers can be connected

to the RS-485 Panel Bus, providing a total of 256

outputs and 64 monitored inputs

 Powered by 24V DC, redundant, monitored

 Lamptest

 LED intensity control

 Designed to meet EN 54 and SOLAS

requirements, and conforms to CE standards

Application/Description

The Mimic Cabinet BUR-200 is specifically designed

for use in maritime applications. It consists of 1

Mimic Driver BUR-200 and 16 programmable relays.

One Mimic Driver that is capable of driving 32 LEDs

with series resistors on a mimic panel for additional

indication of alarms. In addition, 8 standard

monitored inputs can be used for reading various

switches.

The Mimic Driver is connected to the RS-485 Panel

Bus (see drawing on next page).

Power redundancy is achieved by using a daisy

chain connection with master and slave drivers.

For detailed information on the Mimic Driver, refer to

separate datasheet for BUR-200.
