Emerson DeltaV S-series Traditional I/O

Easy online expansion: The S-series I/O carriers and interfaces

can easily be added online, without disruption of existing

I/O communication. I/O carriers can be extended online,

either by directly connecting them to the right side of the

existing carrier, or using extender cables to mount the new

carrier on a different DIN rail. The controller automatically

detects new carriers and interfaces and allows these to be

auto-sensed into the configuration database.

Field-mounted capable hardware: All S-series traditional I/O

interfaces are rated for extreme operating temperature ranges

of -40 to 70°C (-40 to 158°F). The interfaces can be installed

in field mounted enclosures so you significantly reduce the

footprint of your equipment and increase valuable control room

space for other uses. This also allows you to save on wiring

expenses by eliminating the need for long runs of multi-cores.

The integrated design of the I/O subsystem can eliminate the

need for marshaling panels. This saves you even more in your

total capital costs.

1:1 Redundancy for traditional I/O cards: Increased

system availability is easy with S-series traditional I/O cards.

Four traditional I/O card types are available with redundant

terminal blocks for critical field circuits. Simply install a pair

of cards on the prescribed redundant terminal block and the

DeltaV Distributed Control System (DCS) will automatically

recognize them as a redundant pair. There is no configuration

other than to autosense the redundant pair.

Plug-and-play I/O: All S-series traditional I/O components

plug into the I/O interface carrier and are auto sensed by

the controller. There are no addressing switches or jumpers.

Cards can be installed in any order simplifying the I/O

subsystem design. New I/O interfaces are detected by the

system and added to the engineering database automatically.

Additional features can be enabled as needed and downloaded

without disruption to existing I/O communication,

allowing you to install the I/O you need today with the ability to expand tomorrow.
