KEBA KeControl C1 Control modules

CP 035/M, CP 056/E, CP 056/Y, CP 057/Y (upon request)

Product features

// Built-in I/O elements

// Expandable I/O elements and drive

technology via EtherCAT

// CAN and serial interfaces for peripheral devices

// Fast Cut-Off Reaction, Fast Reaction Control,

and Fast Closed-Loop Control

// Flat design

Brief description

CP 035/M and CP 05x are central control modules that have been optimized for the end-to-end automation of applications

with high I/O counts, such as injection molding machines, die-casting or extrusion machines.

The large number of digital and analog input and output signals, the direct actuation of proportional valves, and the

connection of temperature sensors make it possible to fully automate a wide variety of applications using just one

component.

The optimized interaction between the KEBA hardware and the control modules is key for perfect results. For example

in injection molding machines, innovative control features such as Fast Cut-Off Reaction, Fast Reaction Control, and

Fast Closed-Loop Control as well as direct hardware support with response times up to 62.5 µs are able to improve the

process control performance and consequently improve the quality of the parts, and reduce rejects. At an injection speed

of 500 mm/s and a cycle time of 1ms, Fast Cut-Off Reaction achieves a switch-over point accuracy of 32 µm.
