Eaton Power Xpert quality event analysis system Beyond metering

Unparalleled performance.

Unmatched potential.

PXQ not only enhances efficiency, accuracy, and visibility in root cause

analysis, but it does all these things within a system that was intentionally

designed to grow and adapt with the user. With PXQ, unmatched potential

meets unparalleled performance.

PXQ combines ANSI C12.20 Class 0.1 accuracy with stringent power quality

standards and context-driven visualizations, culminating in a modular system

that doesn’t only work better, but with seamless and intuitive functionality.

What’s included

With on-board analytics, remote system access, advanced cybersecurity,

and future-focused interactive functionality, PXQ was designed to simplify

and fine tune your root cause and data analysis processes, empowering

you to do your best work your way.

How it works

Power, performance, and productivity at-a-glance. PXQ streamlines analysis

and data management with on board analytics, interactive reporting, and

a proactive alert system.

User experience

PXQ has web-based software onboard, providing comprehensive support for

advanced features. This flexibility offers users the ultimate interactive

experience with stunning visuals, graphs, personalized data panels, and more.

Modular expansion

Your power quality meter should grow and adapt to your changing business

needs. PXQ provides field installable options for additional capability, allowing

future expansion.

Power Quality Health Index

(an Eaton exclusive)

Protect the integrity of your most critical systems with Eaton’s patented PQ

Health Index, which provides an intelligent read-out of circuit health based

on statistical analysis of power quality events and disturbances.

Bringing it all together

With 2-minute RMS, 120 cycle waveform, and +/- 0.1 ms event sequencing

recording, PXQ automatically categorizes sags and swells by severity, then

displays the totals on the industry standard ITIC plot. SEMI-F47 is supported

as well.

Enhanced Capture Module (PXQ-ENH)

• Detects and records high-speed voltage transients, which are short, high

-intensity surges that can cause equipment degradation. Transients can cause

costly disruptions and premature equipment failure

• Captures high-speed voltage transients as short as 100ns duration and up

to 10kV magnitude

• Provides detailed waveform data with 1 cycle (17ms)

COMTRADE at 167.000 samples per cycle

Expanded Input Module (PXQ-SER)

• Supports up to 40 digital inputs: 8 built-in, and up to 2 expansion modules

with 16 inputs each)

• Monitors and alerts on the statuses of breakers, UPS, generators, and more.

Meter integration of inputs simplifies switchgear design and root cause analysis

• High accuracy time stamps and historical recording help recreate timelines

around faults or disturbances for efficient root cause analysis

• Pulse counting converts inputs from other utility meters and provides an

integrated view of multiple utilities with a built-in WAGES dashboard
