Prosoft AN-X-TI EtherNet/IP to Texas Instruments Remote I/O Master Gateway, non-CE

The EtherNet/IP™ to Texas Instruments™ Remote I/O Master gateway allows an

Allen-Bradley® Programmable Automation Controller (PAC) to control TI 505 Remote

I/O. This gateway allows a phased migration approach to be used when upgrading or

replacing TI Remote Base Controllers. The gateway provides automatic creation of

the TI Remote I/O scan-list and generates the associated RSLogix™ 5000 tags

reducing engineering effort. Once the new PAC is commissioned the legacy I/O can

be upgraded one module or one rack at a time as scheduled downtime is available.

This gateway minimizes the risk of excessive downtime when upgrading legacy

control systems.

TI 505 Features:

 Configures through a web browser (No special configuration software required)

 Scans up to 15 Remote I/O bases and supports both high and low density I/O modules

 Auto-Configuration feature discovers bases and I/O points reducing configuration errors

 Auto-Configuration files are customizable providing additional flexibility for the application

and migration phases

 Supports offline configuration through a .CSV file

 Ability to view configuration and diagnostics through a web browser enabling remote

monitoring or troubleshooting

 Multi-colored LED that indicates the status of the Remote I/O network connection

EtherNet/IP™ Features:

 Supports up to 16 I/O connections to reliably transport data to the PAC

 Each connection can have a unique RPI from 5 to 750 mSec allowing the PAC to

process the I/O data efficiently

 Auto-Configuration feature maps the discovered TI 505 I/O points into tags in the PAC controller.

 Auto-Configuration files are customizable providing additional flexibility for the application

and migration phases

 Ability to view configuration and diagnostics through a web browser enabling remote monitoring

or troubleshooting

 Diagnostic data can be mapped into PAC memory making this data available to HMIs

 Ethernet network LEDs to show link and activity
