ABB Symphony Plus Flame Scanner UvisorTM SF810i

From:ABB | author:Mr.Chen | Time :2024-07-15 | 783 view: | Share:

- Automatic tuning

Flame Explorer

If the SF810i is part of a Modbus network, or if individual SF810i's need to be configured or queried, ABB offers the engineering tool Flame Explorer.

This tool will configure and query the device. Trained operators can set flame out and pull-in limits with the correct passwords.

as well as parameters for optimising flame discrimination between burners. In addition, Flame Explore evaluates and records trends in important flame parameters.

including intensity, flicker frequency and flame quality. By monitoring these parameters, operators are able to identify problems before they lead to severe burner deterioration and develop preventative maintenance programmes.

ENVIRONMENT

- ATEX II 2GD Ex d IIC T6 Gb Ex tb IIIC T 80°C Db IP66/67

- ICEPI 06 ATEX 03C024

Installation

- Sighting with sighting accessories

- Fibre optic cable through the bellows
