ABB Instrumentation 2600T Pressure Transmitter family

INTRODUCTION

Instruction Manual Structure

The present manual provides information on installing, operating, troubleshooting the 364 pressure transmitter.

Every section of the present manual it is specifically dedicated to the specific phase of the transmitter

lifecycle starting from the receipt of the transmitter and its identification, passing to the installation,

to the electrical connections, to the configuration and to the troubleshooting and maintenance operations.

General Safety Information

The "Safety" section provides an overview of the safety aspects to be observed for operation of the device.

The device has been constructed in accordance with the state of the art and is operationally safe.

It has been tested and left the factory in perfect working conditions.

The information in the manual, as well as the applicable documentation and certificates,

must be observed and followed in order to maintain this condition throughout the period of operation.

Full compliance with the general safety requirements must be observed during operation of the device.

In addition to the general information, the individual sections in the manual contain descriptions of processes or procedural instructions with specific safety information.

Only by observing all of the safety information you can reduce to the minimum the risk of hazards for personnel and/or environment.

These instructions are intended as an overview and do not contain detailed information on all available models or

every conceivable event that may occur during setup, operation, and maintenance work.

For additional information, or in the event of specific problems not covered in detail by these operating instructions,

please contact the manufacturer. In addition, ABB declares that the contents of this manual are not part of any

prior or existing agreements, commitments, or legal relationships; nor are they intended to amend these.

All obligations of ABB arise from the conditions of the relevant sales agreement,

which also contains the solely binding warranty regulations in full.

These contractual warranty provisions are neither extended nor limited by the information provided in this manual.

Improper use

It is prohibited to use the device for the following purposes:

• As a climbing aid, e.g., for mounting purposes

• As a support for external loads, e.g., as a support for pipes, etc.

• Adding material, e.g., by painting over the name plate or welding/soldering on parts

• Removing material, e.g., by drilling the housing.

Repairs, alterations, and enhancements, or the installation of replacement parts, are only permissible as far as these are described in the manual.

Approval by ABB must be requested for any activities beyond this scope. Repairs performed by ABB-authorized centers are excluded from this.

Technical limit values

The device is designed for use exclusively within the values stated on the name plates and within the technical limit values specified on the data sheets.

The following technical limit values must be observed:

• The Maximum Working Pressure may not be exceeded.

• The Maximum ambient operating temperature may not be exceeded.

• The Maximum process temperature may not be exceeded.

• The housing protection type must be observed.

Warranty provisions

Using the device in a manner that does not fall within the scope of its intended use, disregarding this manual,

using under-qualified personnel, or making unauthorized alterations, releases the manufacturer from any liability for any resulting damage.

This makes the manufacturer's warranty null and void.
